complexType AirspaceDesignatorType

diagram
namespace	http://www.fixm.aero/base/4.2
type	extension of fb:RestrictedAirspaceDesignatorType
properties	base  fb:RestrictedAirspaceDesignatorType
used by	element  AtcUnitReferenceType/controlSectorDesignator
facets	Kind  Value  Annotation minLength  1 maxLength  10 pattern  ([A-Z]|[0-9]|[, !"&#$%'\(\)\*\+\-\./:;<=>\?@\[\\\]\^_\|\{\}])*
attributes	Name   Type   Use   Default   Fixed   Annotation href   fb:HypertextReferenceType   optional         documentation Provides an optional mechanism enabling FIXM aeronautical fields to be supplemented with references to AIXM features.  This field should be considered functionally equivalent to the xlink:href field used in AIXM to reference features. [FIXM]
annotation	documentation A published sequence of characters allowing the identification of the airspace. [AIXM 5.1]
source	<xs:complexType name="AirspaceDesignatorType">   <xs:annotation>     <xs:documentation>A published sequence of characters allowing the identification of the airspace. [AIXM 5.1]</xs:documentation>   </xs:annotation>   <xs:simpleContent>     <xs:extension base="fb:RestrictedAirspaceDesignatorType">       <xs:attribute name="href" type="fb:HypertextReferenceType" use="optional">         <xs:annotation>           <xs:documentation>Provides an optional mechanism enabling FIXM aeronautical fields to be supplemented with references to AIXM features.  This field should be considered functionally equivalent to the xlink:href field used in AIXM to reference features. [FIXM]</xs:documentation>         </xs:annotation>       </xs:attribute>     </xs:extension>   </xs:simpleContent> </xs:complexType>

attribute AirspaceDesignatorType/@href

type	fb:HypertextReferenceType
properties	use  optional
annotation	documentation Provides an optional mechanism enabling FIXM aeronautical fields to be supplemented with references to AIXM features.  This field should be considered functionally equivalent to the xlink:href field used in AIXM to reference features. [FIXM]
source	<xs:attribute name="href" type="fb:HypertextReferenceType" use="optional">   <xs:annotation>     <xs:documentation>Provides an optional mechanism enabling FIXM aeronautical fields to be supplemented with references to AIXM features.  This field should be considered functionally equivalent to the xlink:href field used in AIXM to reference features. [FIXM]</xs:documentation>   </xs:annotation> </xs:attribute>
